The innovative formwork solution LOGO.pro can be anchored either from just one side or in the conventional manner.
Lightweight formwork NeoR
PASCHAL provides the ideal solution for every formwork task. Due to the low weight (30 kg/m²), the NeoR can be moved easily by hand – ideal for construction sites, even without a crane.
Intelligent concrete monitoring in real time with Maturix™
An analysis of the concrete strength is carried out by means of intelligent, wireless radio transmitters – this allows both improved planning and realtime monitoring independent of location and time.
Ideas and plans become reality with the PASCHAL AR app
The PASCHAL AR app makes it possible to present the planned formwork solution in original size on an area in real surroundings by means of a smartphone or tablet.
With PPL 12.0, using the digital 3D models for work preparation, cycles and automatic formwork planning with material lists for scheduling and managing the formwork is made a reality across the board. The interface to the PASCHAL AR app makes it possible to use in mobile form on the construction site.
Secure and cost-effective formwork using work safety systems from PASCHAL. Only when the workplace is secure work can be quick, correct and efficient.
Leasing PASCHAL formwork with PASCHAL Ident
PASCHAL not only supports its clients with formwork technology, it also provides indirect support by financing formwork systems. All Modular and LOGO.3 formwork panels are equipped with RFID technology (PASCHAL Ident). This guarantees unique identification that cannot be misunderstood and is a requirement for other types of financing such as leasing.
Plastic filler pieces
Faster forming within the system
Plastic filler pieces enable centimetre precise forming within the system.
This saves time and material compared to using timber filler pieces manufactured by site. Plastic filler pieces are available for all panel and segment heights and depending on the system in widths of 1 to 4 or 1 to 6 cm.
The formwork planning and warehouse management software PASCHAL-Plan light (abbreviated to PPL) supports every building contractor or planning engineer in large building firms so that the use of formwork can be planned to the very best and the site can be supplied in due time with the necessary equipment available in the warehouse.
Precast wall adapter for concreting platform LOGO
The precast wall adapter enables the use of concreting platform at precast wall elements. Instead of the fixing piece the precast wall adapter will be mounted to the concreting platform.
Support bracket LOGO adjustable
Support of formwork during several concrete steps upwards where no platform shall be used.
Modular foundation tie clamp
Delivered as roll the perforated tie can be cut at any foundation width.
Simple installation with the Modular Universal Formwork. The Modular foundation tie clamp will be attached to every panel joint without any additional parts.
Suspending piece for pros
with spring lock
For bracing of precast parts as precast wall panels or reinforced concrete columns.
LOGO.3 Concreting platform
As complete part, the concreting platform is comprised of two stiffening brackets, the boarding and a guard railing. All components are connected together by articulating joints and can be folded up in a space-saving way for transport or storage.
PASCHAL offers sophisticated flexible climbing brackets that adapt perfectly to more specific construction settings – with positive potential in flexibility and time saving. The climbing brackets can be combined with all PASCHAL formwork systems.
TG 60 Shoring Tower
The shoring frames TG 60 are made of steel tube of higher strength and are stiffened with 2 small diagonal braces. Every vertical standard can be loaded with up to approx. 6 tons.
To transfer tensile forces, every frame is secured by hinged pins, locking pins or bolts to each other. In this way the towers can be assembled on the ground and placed by a crane. The shoring frames TG 60 are designed symmetrically – because of that you don’t have to care about the direction of the diagonal braces.
LOGO.3 Special Highlights
The flexible formwork system LOGO.3 offers the ideal applicability for different complex demands on site. The panel range goes from 240 cm wide large-size panels to small plastic fillers. With our innovations you can plan and implement now the application for your construction project in a more optimal way.
Modular column formwork adjustable
The adjustable Modular column formwork by PASCHAL is a steel frame formwork whose elements are assembled according to the so-called windmill principle.
with steel facing
Large-size system for residential and commercial buildings, industrial construction, civil engineering, reservoir construction.
Online Customer Portal checkinsite
Clear access to shipping documents and daily updated overview of your construction site.
The delivery notes and returns are stacking up. How much rental material is actually located on site? This is a question that comes up repeatedly and can only be resolved with time-consuming research and rechecking. Or with a few mouse-clicks instead. The online customer portal „checkinsite“ from PASCHAL makes it possible.
LOGO foundation tie clamp
for every foundation width
Delivered as roll the perforated tie can be cut at any foundation width.
Simple installation with the LOGO.3 wall formwork. The LOGO foundation tie clamp will be attached to the long hole of the LOGO profile without any additional parts.
TTK Circular Trapezoidal Girder Formwork with clamp connection
The Circular formwork with new connection method.
Less connecting pieces, fast segment connection, the clamps can be “stored” at the segment, stepless segment positioning with height offset.
New LOGO.3 panel sizes
270 x 340 cm, 135 x 340 cm
The dimensions of the new panels are completing very advantageously the product range.
In residential construction, formwork is often used for the basement area; here the typical height is 2.70 m. By comparison, in industrial construction the formwork height is typically 3.40 m. So the 3.40 m x 2.70 m panel is optimized for all kinds of construction site.
LOGO.3 Dismantling inside corner post
Dismantling – make it easy
There is a hexagonal nut at the upper side of the inside corner post which will be turned to dismantle (clockwise) for dismantling and anticlockwise for pushing in right position before concreting. A spanner size 36 or a tie rod DW15 put in the hole of the hexagonal nut will be sufficient for turning.
Your individual formwork solution
PASCHAL Custom formwork – A category of its own!
For special fields of application like formwork for columns, piers and shafts or tunnels and vault constructions PASCHAL is working at special formwork solutions for extraordinary geometries and high number of reuses in close co-ordination with its customers.
PASCHAL System formwork in your company colour
Company colours make a big difference in a company’s image. One increasingly sees equipment on construction sites that is not in the equipment manufacturer’s colours, but in the company colours of the construction company. That which was initially only possible for large vehicles is now also available for concrete formwork.
